總述

Summary

滾邊機是用來徹底清除輪輞壓延成型以后生的輪輞邊邊毛邊的全相互輔助史詩武器，以冷滾壓的體例止住修緣至油滑過于，做好提高輪輞品行的請求。該輔助史詩武器要加工生產各規格尺寸小線輪輞，加工生產規模性廣，輔助史詩武器列席gps精度不高，認同全相互化保障體系，釣魚任務效力待定高，布局合理干硬。Roll edge machine is used to remove the burr of rim both edge after rim roll forming, adopt cold rolling way to process the rim edge upto smooth, to achieve the requirements of improving the rim quality. The equipment can process the size at diameter 13-17 inch of car rim line, this machine use fully automated system with high efficiency, compact structure.

規格參數

Specification

史詩裝備產品型號	Model Number	GBJ-350
輪輞主要間距	Max. Width of Rim Band	290mm
輪輞最大的直經	Max. Diameter of Rim Band	18 inches
輪輞最大直勁	Mini. Diameter of Rim Band	13 inches
輪輞最多厚薄	Max. Thickness of Rim Band	5mm
一側上限滾邊力	Rolling Force of Single Side	1.7Tons
收窄良好環境	Pressure of Compressed Air	0.4-0.6Mpa
偏側滑輪可調節為劑接連	Adjustable Distance of Single Si de Roller	150mm
滾邊輪速比	Roller Speed	230r/min

特點

1) 啟動法式風格Running Process

加料→中鍵相互下壓→擴張→消弭飛邊→中鍵趕緊→卸料→卸料裝配工藝下落→上下料籌備一工件的相互進行。

徹底游戲裝備會去主動化質量高，格局時緊時松，每日任務效力待定高。

feed material→ roller wheel press down automatically→ rotation→ remove burr→ roller wheel releases→ material unload→ unloading device goes down→ prepare unloading→ workpiece enters automatically.The equipment has high automatically production level, intensive structure, and high working efficient.

2) 配備全自主的性化，創新舉措成功體例上長單動操控、帶有大量手動操控和自主的性操控的好處。

極品裝備工作措施思維由PLC規范，幽靜靠經得住

The equipment is full automatically, whose operation mode has single operation, manual and auto operation.

Its operation logic is controlled by PLC.

3) 操控操作界面（HMI）妙手動上傳加工處理多型號鋼圈的研究生調劑后技術參數并日常的儲存，以作能夠侵占，能能也許顯露轉備內控旌旗燈號的修改請況和時時請況。

On operating interface (HMI) can input adjusted parameter of every rim size manually and record them to call parameter instantly. It also shows the set condition of equipment’s external signal and its current condition.

4) 結余料清算通道長度、壓緊輪程度、擋料的地位、下滾模滾邊坡度等級任務主要參數可采取的差別品種的鋼圈中斷才能購買到合適的。

The working parameters, like width of loading/unloading path, pressing wheel’s height, material baffle position, roll-edge dip angle of lower rolling tool, can be adjusted according with different rim specifications.

5) 傳奇裝備預備會議結構不改靠經經得住，抗振包能好；必備條件充沛的靠經經得住性,在質保期刻日內有充沛的密度、鋼度、不改性、耐沖刷性、抗委靡性。

Equipment’s over-all structure is stable and reliable with excellent shakeproof ability. It is reliable enough to keep sufficient strength, rigidity, stability, corrosion resistance, fatigue resistance.

6) 雙旋輥架（面前）負擔隨意調節節為式，發動機轉速120~200轉/分，上輥子油路分配器壓緊，負擔隨意調節節為式4-8kg/cm2，收入支出料架參數隨意調節節為式6"-16.5"，所有一切路途放肆、社會地位放肆、有沒能什么有類件展現均進行雙位無接觸點感到恐懼展現，實現展現滿有了解。

缺件，清幽高速運轉時各生產步驟都提升綠燈，有問題時某生產步驟提升紅綠燈并報警聲音響鈴提升，方便隨時處里。在改換結果時，凡是改換下模模頭，和專業專業調劑毛刺現象輥的坡度，專業專業調劑之時 為四分鐘。

The pressure of double rotation roller rack can be adjusted. Its rotation speed is 120~200r/min. Pressure adjustable range is 4-8kg/cm2 (0.4-0.8Mpa) for pneumatic clamping of upper material pressing roller. Width of material loading/unloading path adjustable range is 6"-16.5". All the stroke control, position control, workpiece display adopt two-position noncontacting sensor vision.

In situation when without workpiece or safe running green indicator lights. When fault occurs, some process will light red indicator and alarm to dial with problems. It just need to change lower tool and adjust angle of deburr roller when change products. The adjustment time is 4 minutes.
